IFC™Valve
INTEGRATED® IFC™ gate valve is used in various oil and gas drilling applications that includes blowout preventers, choke and kill manifolds, wellhead valves, and in many other applications. This provides reliable and durable performance in high-pressure applications.
Pressure Control Valve for Snubbing, Workover, Drilling & Production Application
(Flow Control – Blowout Preventers – 16A │ Choke & Kill Manifolds – 6A │ Wellhead Valves – 6A)
IFC™Valve SPECIAL FEATURES
INTEGRATED® IFC™ is a field proven valve which provide reliability and interchangeability. Our IFC™ slab gate valve features a forged steel body and bonnet, non-rising stem with a floating slab gate & seat and a full-bore design.
- Available with SS316 Inlay or Inconel 625 Cladded ring grooves and seat pockets
- Tungsten Carbide coated Gate and Solid Stellite Seat Rings for better wear and abrasion resistance
- Inconel grease fittings for better performance and temperature endurance
- MOS2 coated Stem for lower operating torques
- Temperature Rating up to -50oF TO 350oF
- Zinc or Cad Plated Bonnet Bolts and Nuts for better corroison resitance
- Interchangeable with Cameron FC Style Valve
- Available with SS316 Inlay or Inconel 625 Cladded ring grooves and seat pockets
- Tungsten Carbide coated Gate and Solid Stellite Seat Rings for better wear and abrasion resistance
- Inconel grease fittings for better performance and temperature endurance
- MOS2 coated Stem for lower operating torques
- Temperature Rating up to -50oF TO 350oF
- Zinc or Cad Plated Bonnet Bolts and Nuts for better corroison resitance
- Interchangeable with Cameron FC Style Valve
